Flexible Plastic Composite Gas Pipe

Quantity:
  • DN17mm to 200mm
  • OEM
  • 83071000
Flexible Plastic Composite Gas Pipe

Characteristics:
Anti-H2S, CO2, good insulation and abrasion resistant performance, anti-flaming, antistatic, constructed rapidly, no fire operation, high safety factor.

Product structure:
Consisted by core pipe, enhancement layer (fiber
Enhancement, steel wire enhancement), and external protective layer.

Performance:
Specification: 25~200mm
Safety Factor: 2
Working temperature: -50~90 C
Working pressure: ≤ 32MPa

Note: We can design and produce flexible composite hose of various specifications as per customer's request.
List for product specifications
Minimum inner diameter(mm) Nominal wall thickness (mm) Nominal pressure(MPa)
25  8.0 32.0
25 6.0 32.0
40 9.0 25.0
40 8.5 16.0
50 11.0 25.0
50 10.5 16.0
60 13.0 25.0
65 15.0 25.0
65 13.0 16.0
75 16.0 16.0
90 14.0 16.0
102 15.0 16.0
125 13.5 6.4
150 14.0 6.4
175 15.0 6.4
200 17.0 6.4
