Flexible Composite Pipe for Alcohol Injecting Pipe Series Characteristics:
Good performance to resist organic alcohol, constructed rapidly, cost saving.
Product structure:
Consisted by core pipe, enhancement layer (fiber enhancement, steel wire enhancement), and external protective layer.
Performance:
Specification: 17~50mm
Safety Factor: 2
Working temperature: -50~80 C
Working pressure: ≤ 48MPa
Note: We can design and produce flexible composite hose of various specification as per customer's request.
| List for product specifications |
| Minimum inner diameter(mm) | Nominal wall thickness (mm) | Nominal pressure(MPa) |
| 17 | 7.0 | 48.0 |
| 17 | 6.0 | 32.0 |
| 25 | 8.0 | 32.0 |
| 25 | 6.5 | 32.0 |
| 25 | 6.0 | 25.0 |
| 25 | 5.5 | 16.0 |
| 25 | 5.0 | 12.0 |
| 40 | 10.0 | 32.0 |
| 40 | 9.0 | 25.0 |
| 40 | 8.5 | 16.0 |
| 40 | 8.0 | 12.0 |
| 40 | 6.5 | 6.4 |
| 50 | 12.0 | 32.0 |
| 50 | 11.0 | 25.0 |
