| Quantity: | |
|---|---|
1/4" 5/16" 3/8" 1/2" 3/4" 1" 1-1/4" 1-1/2" 2"
OEM
| Type | Rated work pressure Mpa | Flow rate L/h | Plunger diameter mm | Range (mm) | Electric Motor power KW | Size Length*width*height | Weight KG |
| 3D-SY100mpa | 100 | 122 | 12 | 40 | 5.5 | 1690*675*1000 | 630 |
| 3D-SY125mpa | 125 | 84.70 | 10 | ||||
| 3D-SY160mpa | 160 | 68.70 | 9 | ||||
| 3D-SY200mpa | 200 | 54 | 8 |
| Type | 3D-SY 33/6 | 3D-SY 20.6/12 | 3D-SY 13.2/20 | 3D-SY 8.4/30 | 3D-SY 6.5/40 | 3D-SY 4.1/60 | 3D-SY 2.7/80 |
| Rated discharge pressure MPA | 6 | 12 | 20 | 30 | 40 | 60 | 80 |
| Rated flow rate (L/H) | 33 | 20.6 | 13.2 | 8.4 | 6.5 | 4.1 | 2.7 |
| Plunger diameter (mm) | 95 | 75 | 60 | 48 | 42 | 34 | 28 |
| PlungerRange(mm) | 105 | ||||||
| Reciprocating Times | 268 | ||||||
| Electrical rotational speed | 1500 | ||||||
| Power of motor KW | 75 | ||||||
| Type | 3D-SY 13.57/6 | 3D-SY 11.56/8 | 3D-SY 8/12 | 3D-SY 5.66/16 | 3D-SY 4.64/20 | 3D-SY 2.89/30 | 3D-SY 2.34/40 | 3D-SY 1.55/60 | 3D-SY 1.25/70 | 3D-SY 1.16/80 | 3D-SY 1.82/100 |
| Rated discharge pressure MPA | 6 | 8 | 12 | 16 | 20 | 30 | 40 | 60 | 70 | 80 | 100 |
| Rated flow rate (L/H) | 13.57 | 11.56 | 8 | 5.66 | 4.64 | 3.89 | 2.34 | 1.55 | 1.28 | 1.16 | 0.82 |
| Plunger diameter (mm) | 65 | 60 | 50 | 42 | 38 | 30 | 27 | 22 | 20 | 19 | 16 |
| PlungerRange(mm) | 60 | ||||||||||
| Reciprocating Times | 380 | ||||||||||
| Electrical rotational speed | 1470 | ||||||||||
| Power of motor KW | 30 | ||||||||||
| Type | Rated work pressure Mpa | Flow rate L/h | Plunger diameter mm | Range (mm) | Electric Motor power KW | Size Length*width*height | Weight KG |
| 3D-SY100mpa | 100 | 122 | 12 | 40 | 5.5 | 1690*675*1000 | 630 |
| 3D-SY125mpa | 125 | 84.70 | 10 | ||||
| 3D-SY160mpa | 160 | 68.70 | 9 | ||||
| 3D-SY200mpa | 200 | 54 | 8 |
| Type | 3D-SY 33/6 | 3D-SY 20.6/12 | 3D-SY 13.2/20 | 3D-SY 8.4/30 | 3D-SY 6.5/40 | 3D-SY 4.1/60 | 3D-SY 2.7/80 |
| Rated discharge pressure MPA | 6 | 12 | 20 | 30 | 40 | 60 | 80 |
| Rated flow rate (L/H) | 33 | 20.6 | 13.2 | 8.4 | 6.5 | 4.1 | 2.7 |
| Plunger diameter (mm) | 95 | 75 | 60 | 48 | 42 | 34 | 28 |
| PlungerRange(mm) | 105 | ||||||
| Reciprocating Times | 268 | ||||||
| Electrical rotational speed | 1500 | ||||||
| Power of motor KW | 75 | ||||||
| Type | 3D-SY 13.57/6 | 3D-SY 11.56/8 | 3D-SY 8/12 | 3D-SY 5.66/16 | 3D-SY 4.64/20 | 3D-SY 2.89/30 | 3D-SY 2.34/40 | 3D-SY 1.55/60 | 3D-SY 1.25/70 | 3D-SY 1.16/80 | 3D-SY 1.82/100 |
| Rated discharge pressure MPA | 6 | 8 | 12 | 16 | 20 | 30 | 40 | 60 | 70 | 80 | 100 |
| Rated flow rate (L/H) | 13.57 | 11.56 | 8 | 5.66 | 4.64 | 3.89 | 2.34 | 1.55 | 1.28 | 1.16 | 0.82 |
| Plunger diameter (mm) | 65 | 60 | 50 | 42 | 38 | 30 | 27 | 22 | 20 | 19 | 16 |
| PlungerRange(mm) | 60 | ||||||||||
| Reciprocating Times | 380 | ||||||||||
| Electrical rotational speed | 1470 | ||||||||||
| Power of motor KW | 30 | ||||||||||
