3000psi Constant Pressure R17 One or Two Wire Braid Flexible High Pressure Hydraulic Oil Hose

Tube: Black, oil resistant Nittrile (BTR) tube
Reinforcement: One or Two braids of high tensile steel wire reinforcement (sizes -04 and -06 have only one braid)
Cover: Oil and abrasion resistant, black Neoprene cover for long wear
Temperature range: -40° To +212° F
Quantity:
  • 1/4" 3/8" 1/2" 3/4" 1" 1-1/4" 1-1/2" 2"
  • OEM
  • 4009210000
  • SAE 100 R17
  • Hydraulic Oil Delivery
  • NBR
  • NBR
  • One or Two Wire Braid
  • 3000psi
  • 4:1
R17 Super Flexible Single or Double Wire Braid High Pressure Hydraulic Hose

One or Two braids of high tensile steel wire reinforcement (sizes -04 and -06 have only one braid)

Tube: Black, oil resistant Nittrile (BTR) tube
Reinforcement: One or Two braids of high tensile steel wire reinforcement (sizes -04 and -06 have only one braid)
Cover: Oil and abrasion resistant, black Neoprene cover for long wear
Temperature range: -40° To +212° F

Hydraulax
Item Number
Inside
Diameter
Outside
Diameter
Maximum Working
Pressure (PSI)
Minimum Burst
Pressure (PSI)
Minimum Bend
Radius
R17-04 1/4" 0.55" 3,000 12,000 2"
R17-06 3/8" 0.67" 3,000 12,000 2-1/2"
R17-08 1/2" 0.81" 3,000 12,000 3-1/2"
R17-10 5/8" 0.93" 3,000 12,000 4"
R17-12 3/4" 1.07" 3,000 12,000 4-3/4"
R17-16 1" 1.37" 3,000 12,000 6"
